Messier 64 - The Black Eye Galaxy

Description:

"This galaxy is known to contain two nested, counter rotating, gas disks of a few 108 solar mass each, with the inner disk extending to approximately 1 kpc and the outer disk extending beyond. The stellar kinematics along the major axis, extending across the transition region between the two gas disks, show no hint of velocity reversal or increased velocity dispersion.  The stars always rotate in the same sense as the inner gas disk, and thus it is the outer disk which 'counterrotates'. The projected circular velocities inferred from the stellar kinematics and from the H I disks agree to within approximately 10 km/s, supporting other evidence that the stellar and gaseous disks are coplanar to approximately 7 deg. This upper limit is comparable to the mass of detected counter rotating gas. This low mass of counter rotating material, combined with the low-velocity dispersion in the stellar disk, implies that NGC 4826 cannot be the product of a retrograde merger of galaxies, unless they differed by at least an order of magnitude in mass. The velocities of the ionized gas along the major axis are in agreement with that of the stars for R less than 0.75 kpc. The subsequent transition toward apparent counter rotation of the ionized gas is spatially well resolved, extending over approximately 0.6 kpc in radius. The kinematics of this region are not symmetric with respect to the galaxy center. On the southeast side there is a significant region in which vproj (H II) much less than vcirc approximately 150 km/s, but sigma (H II) approximately 65 km/s. The kinematic asymmetries cannot be explained with any stationary dynamical model, even is gas inflow or warps were invoked. The gas in this transition region shows a diffuse spatial structure, strong (N II) and (S II) emission, as well as the high-velocity dispersion. These data present us with the conundrum of explaining a galaxy in which a stellar disk, and two counter rotating H I disks, at smaller and much larger radii, appear in equilibrium and nearly coplanar, yet in which the transition region between the gas disks is not in steady state."

"The Evil Eye galaxy (NGC 4826; M64) is distinguished by an asymmetrically placed, strongly absorbing dust lane across its prominent bulge. We obtained a long-slit spectrum of NGC 4826, with the slit across the galaxy's nucleus, covering equal parts of the obscured and the unobscured portions of the bulge. By comparing the spectral energy distributions at corresponding positions on the bulge, symmetrically placed with respect to the nucleus, we were able to study the wavelength dependent effects of absorption, scattering, and emission by the dust, as well as the presence of ongoing star formation in the dust lane. We report the detection of strong extended red emission (ERE) from the dust lane within about 15 arcsec distance from the nucleus of NGC 4826. The ERE band extends from 5400 A to 9400 A, with a peak near 8800 A. The integrated ERE intensity is about 75 % of that of the estimated scattered light from the dust lane. The ERE shifts toward longer wavelengths and diminishes in intensity as a region of star formation, located beyond 15 arcsec distance, is approached. We interpret the ERE as originating in photoluminescence by nanometer-sized clusters, illuminated by the galaxy's radiation field, in addition to the illumination by the star-forming complex within the dust lane. When examined within the context of ERE observations in the diffuse ISM of our Galaxy and in a variety of other dusty environments such as nebulae, we conclude that the ERE photon conversion efficiency in NGC 4826 is as high as found elsewhere, but that the size of the nanoparticles in NGC 4826 is about twice as large as those thought to exist in the diffuse ISM of our Galaxy."

"The close to coplanar orientation of the gas disks is one aspect which is in good agreement with what is expected on the basis of a merger model for the counter-rotating gas. The rotation direction of the inner gas disk with respect to the stars, however, is not. In addition, the existence of a well defined exponential disk probably implies that if a merger did occur it must have been between a gas-rich dwarf and a spiral, not between two equal mass spirals. The stellar spiral arms of NGC 4826 are trailing over part of the disk and leading in the outer disk. Recent numerical calculations by Byrd et al. for NGC 4622 suggest that long lasting leading arms could be formed by a close retrograde passage of a small companion. In this scenario, the outer counter-rotating gas disk in NGC 4826 might be the tidally stripped gas from the dwarf. However, in NGC 4826 the outer arms are leading, while it appears that in NGC 4622 the inner arms are leading. A realistic N-body/hydro simulation of a dwarf-spiral encounter is clearly needed. It may also be possible that the counter-rotating outer gas disk is due to gradual infall of gas from the halo, rather than from a discrete merger event."

History of Observation:

".. on the 23rd of March [1779], I discovered a nebula in the constellation of Coma Berenices, hitherto, I presume, unnoticed; at least not mentioned in M. de la Lande's Astronomy, nor in M. Messier's ample Catalogue of nebulous Stars [of 1771]. I have observed it in an acromatic instrument, three feet long, and deduced its mean R.A. by comparing it to the following stars Mean R.A. of the nebula for April 20, 1779, of 191d 28' 38". Its light being exceedingly weak, I could not see it in the two-feet telescope of our quadrant, so was obliged to determine its declination likewise by the transit instrument. The determination, however, I believe, may be depended upon to two minutes: hence, the declination north is 22d 53"1/4. The diameter of this nebula I judged to be about two minutes of a degree."

"The dark semi-elliptic vacancy (indicated by an unshaded or bright portion in the figure,) which partially surrounds the condensed and bright nucleus of this nebula, is of course unnoticed by Messier. It was however seen by my Father, and shown by him to the late Sir Charles Blagden, who likened it to the appearance of a black eye, an odd, but not inapt comparison. The nucleus is somewhat elongated, and I have a strong suspicion that it may be a close double star, or extremely condensed double nebula."

Locating Messier 64:
